Specifications and Site Requirements
Mechanical Specifications

Precision Rail Dual Array Vehicle

700-1528-00
[1.54]
[0.683]
17.35
[0.906]
23.00
[0.906]
23.00
[1.024]
26.00
Weight: 1.2 kg [2.6 lb]
Figure 4-43: Precision Rail Dual Array Vehicle Mechanical Drawing
NOTICE
Exposed Materials
6061-T6 AL, Anodized per MIL-A8625-F, Type II, Class 2, Black.
Stainless Steel.
316L/316L #2 Stainless Steel.
440C Stainless Steel.
UHMW Polyethylene.
Nitrile.
Plastic.
Mobilgear
192
[3.46]
88.0
C
L
[1.54]
LOCKING HELICOIL INSERTS
39.0
39.0
[5.16]
131.0
[6.392]
162.37
The bearings on the precision rail vehicles must always be
lubricated with a thin coating of oil to provide proper opera-
tion and environmental protection.
600 XP Oil.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
[3.807]
96.70
DIRECTION OF MOTION
[4.553]
115.64
[1.201]
30.51
[1.937]
49.21
All Dimensions in Millimeters [Inches]
[0.803]
20.40
MagneMotion
