Specifications and Site Requirements
Mechanical Specifications
700-1622-02
6X R4
2X 125.0°
Figure 4-47: Precision Rail Straight, No Joint, Spine Plate, Mechanical Drawing
700-1622-05
125.0°
73.58
141.5°
Figure 4-48: Precision Rail Straight, With Joint, Spine Plate, Mechanical Drawing
196
0
10.00
25.00
2X 55.00
85.00
100.00
110.0
2X 145.0°
0
2X 54.98
64.98
124.98
132.0
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
[0.25]
6.35
All Dimensions in Millimeters
[0.25]
6.35
All Dimensions in Millimeters
