Loop Paths
The following figures show simplified connection diagrams of the different methods for con-
necting a loop of motors using Ethernet. The specific connection method that is used depends
on the application for the motors.
Loop Transport System (Recommended):
One Enet Connection, One Chain
One Path
Host Enet
Controller Switch
Figure 3-15: Ethernet Motor Wiring – One Path, One Ethernet Chain
Loop Transport System:
One Enet Connection per Side, Split Chain
One Path
Host Enet
Controller Switch
Figure 3-16: Ethernet Motor Wiring – One Path, Two Ethernet Chains
Loop Transport System:
One Enet Connection per Motor, Star Topology,
One Path
Host Enet
Controller Switch
Enet
Switch
MagneMover LITE User Manual
