Precision Rail Lubrication Pump

+9...30V DC, 0.5 A maximum.
See Precision Rail Lubrication System on page 198
The optional lubrication pump for use with the Precision Rail option requires a DC power
source, typically +24V DC. This power must be supplied to the pump as shown in
Figure 4-64. See the documentation that is supplied with the pump for configuration and oper-
ating information.
Control Cable
M8 Connector
Status Indicator
One-touch Oil Fitting
Figure 4-64: Precision Rail Optional Lubricator Pump Connections
Table 4-31: Precision Rail Optional Lubricator Pump Electrical Connections
Label
—
Label
—
Table 4-33: Precision Rail Optional Lubricator Pump Indicators
Label
—
—
MagneMover LITE User Manual
Description
Control
Table 4-32: Precision Rail Optional Lubricator Pump Controls
Description
Set Button
Description
Display
Status
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Specifications and Site Requirements
Electrical Specifications
for the mechanical drawings.
LCD Display
Set Button
Connector Type
M8 Plug
Control Type
Push button
Indicator Type
LCD
LED
223
