Procedure
1. Stop all motion on the MM LITE transport system.
2. Remove the pucks from the MagneMover LITE transport system (see
on page
3. Inspect the ski wear indicators.
• For pucks that experience uneven wear, rotate the pucks 180°.
• If the wear indicator cutout on either ski has worn down so it is no longer visi-
ble/no longer exists, then replace the ski/top plate. The wear indicator shows
the maximum wear that is allowed before touchdown starts becoming a risk.
4. Replace the pucks on the MM LITE transport system (see
page 399).
MagneMover LITE User Manual
399).
Puck Body
Wear Indicator
Magnet Array
Figure 7-2: Glide Puck Wear Indicator
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Maintenance
Preventive Maintenance
Replace Pucks
DIRECTION OF TRAVEL
Replace Pucks on
