Precision Locator

There is no electrical power requirement for the precision locator, see
tions for the pneumatic power requirements. See
the mechanical drawing. The electrical connections that are shown in
available if the sensor option is installed.
Cylinder Up
Sensor Connection
Cylinder Down
Sensor Connection
Label
—
—
Label
—
MagneMover LITE User Manual
Figure 4-65: Precision Locator Electrical Connections
Table 4-35: Precision Locator Connections
Description
Cylinder Up Sensor Connection
Cylinder Down Sensor Connection
Table 4-36: Precision Locator Sensor Indicators
Description
ON – Indicates that the sensor is active.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Specifications and Site Requirements
Electrical Specifications
Pneumatic Specifica-
Precision Locator Option on page 199
Figure 4-65
Connector Type
M8 Locking, 3-Pin, Plug
M8 Locking, 3-Pin, Plug
Indicator Type
Red Light
for
are only
225
