RS-422 Motor Communication

Host Ethernet
Controller Switch
Figure 5-18: Simplified Representation of RS-422 Motor Connections
Host Ethernet
Controller Switch Controller
Figure 5-19: Simplified Representation of RS-422 Merge Switch Connections
Installing RS-422 Motor Communication Cables
See Figure 4-56 on page 208
connection locations on the motors and switches. See the Node Controller Hardware User
Manual, MMI-UM013, for the communication connection locations on the node controllers.
See Figure 5-18
detailed example. The connections for a diverge switch are different than the connection
shown in Figure 5-19
When connecting the motors to the node controllers, both ends of a path do not need to con-
nect to the same node controller. However, all connections to the motors at the ends of all
paths that meet in a node must be made to the same node controller. See the MagneMover
LITE Configurator User Manual, MMI-UM008, for more information about nodes and paths.
MagneMover LITE User Manual
Upstream
Simple RS-422 Motor
HLC &
Node (Straight or Curve)
Node
Controller
RS-422
Power
Power
Supply
Downstream
Switch Configuration
Upstream
RS-422 Motor
HLC &
(Straight or Curve)
Node
From Previous
Motor in Path
RS-422
Power
Power
Supply
and Figure 4-58 on page 213
and Figure 5-19 for simplified diagrams of the wiring and
for a merge switch.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Transport System Installation
Downstream
RS-422 Motor
(Straight or Curve)
From Previous
Motor in Path
Merge RS-422 Motor
RS-422 Switch
Node (Straight or Curve)
for the RS-422 communication
Installation
Downstream
To Next
Motor in Path
From Last
Motor in Path
To Next
Motor in Path
Downstream
To Next Motor
in Path
To Next
Motor in Path
Figure 5-20 for a
