Replace Wheeled Puck Wear Surfaces, 2-Wheel Pucks - Rockwell Automation MagneMotion MagneMover LITE Original Instructions Manual

Maintenance
Repair

Replace Wheeled Puck Wear Surfaces, 2-Wheel Pucks

This procedure provides instructions to replace worn wear surfaces on the following wheeled
pucks, which are only used in tandem wheeled pucks:
• Wheeled Puck, Tandem, HP, Single.
NOTICE
Required Tools and Equipment
• Wheel, Payload, Urethane, Core, Puck, Wheeled, ML (2X).
• Wheel, Lateral Guide, Urethane, Puck, Wheeled, ML (4X).
• Screw, Shoulder, Soc, 5 mm x 23.5 mm, M4 x 0.7, Dri-Loc (2X).
• Bumper, Puck, Wheeled, ML (2X).
• Screw, Mach, Che, 6 Lobe, SS, M4 x 0.7 x 7.5, Dri-Loc (4X).
416
MAGNETIC FIELD HAZARD: Strong magnets in use.
To avoid severe injury, people with pacemakers and other
medical electronic implants must stay away from the magnet
array on the vehicles (pucks).
PINCH/CRUSH HAZARD: Strong magnets in use.
To avoid injury from strong magnetic attractive forces:
• Handle only one vehicle (puck) or magnet array at a time.
• Do not place any body parts (for example, fingers)
between a magnet array and any ferrous material or
another magnet array.
• Vehicles (pucks) and magnet arrays not being used must
be secured individually in isolated packaging.
Strong magnets in use.
To avoid damage to watches, instruments, electronics, and
magnetic media, keep metal tools, metal objects, magnetic
media (for example, memory disks/chips, credit cards, and
tapes) and electronics away from the magnet arrays.
