Pucks

Pucks are the preconfigured vehicles available from MagneMotion to carry payloads through
the MagneMover LITE transport system on the rails. A high-strength magnet array, described
in Magnet Arrays on page
magnet array interacts with the motors, which move the vehicle. Pucks are available in differ-
ent styles; glide and wheeled. Both puck styles have magnet arrays that are attached to the sur-
face closest to the motors as shown in
When moving at maximum acceleration or velocity, the payload being carried must fit within
the payload envelopes shown in this section to achieve the advertised life of wear compo-
nents. Contact TechConnect
is within the weight specification but outside the envelope specification shown.

Single Array Glide Puck

Glide pucks with single magnet arrays, as shown in
being moved weighs up to 1 kg [2.2 lb]. See
(G5), on page 182
Wear Surfaces
Magnet Array
For proper operation, the payload on the puck must fit within the payload envelope that is
shown in Figure
Puck Limits on page
MagneMover LITE User Manual
98, is mounted to the surface of the puck closest to the motors. The
Figure 3-26
℠
(see Rockwell Automation Support on page
for details.
Puck Body
Figure 3-26: Single Array Glide Puck
3-27. When using payloads that exceed the limits that are shown, refer to
124.
[2.50]
63.5
Figure 3-27: Single Array Glide Puck Payload Envelope
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
and Figure 3-32.
Figure 3-26, are used when the material
Figure 4-34, Glide Puck Mechanical Drawing
[1.18]
30.1
Design Guidelines
Transport System Design
486) if the payload
DIRECTION OF TRAVEL
[2.50]
63.5
