Precision
Locator
Figure 5-44: MagneMover LITE Precision Locator Option, Alternate

Install Pallets and Pucks

Install the pucks with pallets on the system before installing the motors to allow easy installa-
tion.
1.
Mount the pallet on the custom puck if not already installed (see
faces on Pallet on page
2.
Install the puck with the pallet on the system (see
preferred method to add or remove pucks).
NOTE: Make sure that the orientation of the puck locates the pallet correctly at the
MagneMover LITE User Manual
Cover
M3 x 6 mm Screw
(2 + 1X per Locator)
M6 Lock Washer
M6 x 20 mm Bolt
Pneumatic
Connections
448).
precision locator station.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Option Installation
M8 x 20 mm Bolt
M8 Lock Washer
Adjustable Motor Mount
M6 x 12 mm Screw
(2X per Rib)
Stand Rib
Locating Pin
M8 x 30 mm Bolt
(2X per Rib)
M8 Lock Washer
(2X per Rib)
M6 x 25 mm Screw
(4X)
Replace Wear Sur-
Replace Pucks on page 399
Installation
Pallet
Puck
Back Plate
for the
297
