3. Using fingers, align the rails at the motor joints as shown in
two M6 x 12 mm screws on each V-brace at that motor joint to 3.4 N•m [30 in•lb] with
a T30 Torx bit.
4. Tighten the M6 bolt to 5.5 N•m [49 in•lb] with a 10 mm Hex socket to secure the
motor to the motor mount.
For stainless steel rails the Loctite must cure for 2 hours at 22° C [72° F] before using
the transport system.
5. Repeat Step 3
6. Repeat Step 4
Switch Alignment
When aligning and securing the ends of the rails on the motors to the ends of the rails on the
switches, a V-brace is attached over the alignment features on all rails on each switch. For cer-
tain connections extended v-braces are required, see
dard v-braces (200-2002-xx) for all other rail connections.
IMPORTANT Moving the rails on the switches can affect the operation of
MagneMover LITE User Manual
at all motor joints.
at all motors.
the switch and requires recalibration of the switch.
Figure 5-13: Install Standard Switch
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Transport System Installation
Figure
Figure 5-13 and Figure
M6 x 12 mm Screw
(2X per V-brace)
Standard V-brace
(5X 200-2002-XX)
Switch V-brace
(200-2078-XX)
Installation
5-12. Tighten the
5-14. Use stan-
259
