• The standard or adjustable motor mounts can be used to secure the motors to a surface
as shown in
This mounting method may not provide for any adjustment of the motor position once
the motor is installed unless adjustment features are provided in the mounting plate.
MM LITE 1000 mm Motor
M6 x 20 mm Bolt
M6 Lock Washer
When using any of the mounting methods shown.
1. Loosely mount the motors to the motor mounting surface. The motor mounts should
allow the motors a small amount of movement relative to each other.
NOTE: The upstream end of the motor is the end where the power connector is
2. Make sure that there is consistent spacing between the motors.
3. Make sure that the tops of all motors are coplanar to each other.
4. Treating each motor to motor interface as a separate operation, tighten the motor
mounts. See
dure.
MagneMover LITE User Manual
Figure 3-46. The motor mounts provide clearance for all cable routing.
Figure 3-46: Motor Mounting Using Motor Mount Brackets
located (see Figure 4-1 on page 148
Align and Secure Motors and Switches
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Transport System Design
M8 Bolt
M8 Lock Washer
Standard Mounting Bracket
M8 Mounting Hardware
through Figure 4-24 on page
for details of the mounting proce-
Design Guidelines
171).
119
