Use a Lubrication Pump System
Install a lubrication pump system such as catalog number C920600 as shown in
See
Install the Optional Precision Rail Lubrication Pump System on page
Lubrication Port
(2X One Each Side)
Lubrication
Distribution Tubing
Lubrication Pump
Figure 3-59: Precision Rail System with Lubrication Pump System
MagneMover LITE User Manual
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Design Guidelines
Transport System Options
Figure
3-59.
293.
133
