Motion Control Troubleshooting

This section covers the determination of motion-related problems within the MagneMover
LITE transport system.
Symptom
Material slips while the vehicles
are in motion.
Vehicles do not move smoothly
or movement is noisy.
MagneMover LITE User Manual
Table 7-7: Motion Control Related Troubleshooting
Problem Description
Vehicle is not designed to carry
that specific material.
Vehicle is not holding the mate-
rial securely.
Motion configuration issue.
Debris on the guideway.
Misalignment of sections of the
guideway.
Power or communication to the
affected motors is lost or intermit-
tent.
Motion configuration issue.
Excessive noise when the vehicle
moves from motor to motor.
Wheeled puck suspension wheel
tread is damaged.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Maintenance
Troubleshooting
Corrective Action
Make sure that the vehicle design
is correct.
Make sure that all material con-
tact surfaces are clean.
Make sure that the vehicle accel-
eration is correct.
Make sure that the vehicle speed
is correct.
Make sure that the PID values are
correct.
Make sure that the guide rails and
motors are clean.
Make sure that the guide rail
alignment V-braces are properly
installed.
Make sure that the power and
communication cables to all
motors are properly seated.
Make sure that the PID values are
correct.
Make sure that the motors are
properly mounted and the transi-
tion from the rails on one motor to
the rails on the next motor is
smooth (rails must be at the same
height).
Check wheel set. Replace as nec-
essary.
