Attach Tandem Wheeled Puck Linkage Plate Assembly - Rockwell Automation MagneMotion MagneMover LITE Original Instructions Manual

Maintenance
Repair
M6 Shoulder Screw
Thrust Washer
Elastomer Washer
Flange Bearing
Linkage Plate
Thrust Washer
2-3 Drops Loctite
9. Remove the Tandem Wheeled Puck Assembly from the fixture and reinstall on the
MM LITE transport system (see
If the tandem puck is not being reinstalled on the transport system, store it in its origi-
nal packaging or wrapped in bubble-wrap to help protect the puck and to minimize any
safety risks.
424
(2X)
(2X)
(2X)
(2X)
(2X)
(typical)
Figure 7-31: Attach Tandem Wheeled Puck Linkage Plate Assembly
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Replace Pucks on page
Wheeled Puck
Installation
Fixture
Wheeled Puck
399).
MagneMotion
