Stand Side
of Rail
Motor Side
of Rail
Required Tools and Equipment
•
Open-end wrench, 13 mm, thin.
•
Socket wrench, 13 mm.
•
Torque wrench (0.9...26 N•m [8...230 in•lb] range) with the following socket:
•
13 mm Hex.
•
Loctite 290, Thread locker, Wicking Grade, Green.
MagneMover LITE User Manual
Eccentric
Bearings
Dual Array Vehicle
Concentric
Bearings
Figure 7-44: Precision Rail Vehicle Bearing Locations
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Eccentric
Bearings
Single Array Vehicle
Concentric
Bearings
Maintenance
Repair
443
