Outlet Groups

An outlet group is a named collection of selected outlets in a PDU. When user-defined, an outlet group can
contain outlets from different PDUs, including both master and link units.
Outlet groups support fast and efficient outlet control actions (On, Off, Power Cycle) across multiple PDUs, and
with PDU Linking, member outlets for the master and its link units can be collected in the same outlet group.
Outlet groups are managed by the master unit, and multiple outlet groups can be controlled simultaneously.
Summary and power energy readings are available per outlet group.
The Outlet Groups page displays current user-defined outlet groups along with name, outlet state, active power
reading, and the page also shows the outlet labels that were selected for the group. In the Outlets column in this
example you see that outlets from both master and link units display together within a named group. This is an
example of outlet "pairwise", a function described in more detail later in this next section. Note: Outlet groups
can contain multiple pairs of outlets; the next screen example shows only two outlet pairs in the sample groups.
Click the control arrow to toggle the outlet group list in ascending or descending order by group number.
