VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
RISK OF INJURY AND/OR EQUIPMENT DAMAGE
Failure to use the M23 metal blind cap may result in injury to the operator and/or damage to the ISD 510/DSD
510 servo drive.
-
Always fit the M23 metal blind cap as described in steps 10 and 11.
-
An angled version of the M23 connector is also available. The procedure for connecting the angled M23
connector is the same as for the straight connector.

5.9.4 Disconnecting Hybrid Cables

Procedure
1. Disconnect the Power Supply Module (PSM 510) from its power source (mains network and U
2. Wait for the minimum discharge time to elapse.
3. Remove the connector of the feed-in cable from the Decentral Access Module (DAM 510).
4. Rotate the threaded ring on the feed-in cable connector on the servo drive counterclockwise until the marking OPEN on
the cable connector is facing the servo drive.
5. Pull the connector away from the electronic housing.
6.
Protective blind caps are provided for the X1 and X2 connectors. Mount the blind caps after removing the corresponding
connector.

5.9.5 Connecting Cables to Ports X3, X4, and X5

5.9.5.1 Cable Routing Recommendations

Avoid mechanical tension for all cables, especially regarding the range of motion of the installed servo drive.
Secure all cables in accordance with regulations and depending on conditions on site. Ensure that cables cannot come loose, even
after prolonged operation.
