VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
9.3
Error Codes for ISD 510/DSD 510 Servo System
9.3.1
No error (0x0000 / 0x0)
9.3.2
Generic application error (0x1000 / 0x100)
9.3.3
Overcurrent Trip (0x2310 / 0x101)
9.3.4
High cont. current overload (0x2311 / 0x15F)
9.3.5
Continuous current overload (0x2312 / 0x160)
9.3.6
High cont. power overload (0x2313 / 0x161)
9.3.7
Continuous power overload (0x2314 / 0x162)
9.3.8
Overcurrent short circuit (0x2320 / 0x163)
9.3.9
Ground fault (0x2330 / 0x151)
9.3.10
AUX overcurrent (0x2391 / 0x125)
9.3.11
AUX user limit current (0x2393 / 0x127)
9.3.12
AUX user limit current warning (0x2394 / 0x128)
9.3.13
AUX supply failure (0x2395 / 0x129)
9.3.14
Current overload trip (0x2396 / 0x15C)
9.3.15
Power overload trip (0x2397 / 0x12B)
9.3.16
Thermal overload motor (0x239B / 0x102)
9.3.17
Mains phase loss (0x3130 / 0x12F)
9.3.18
DC link overvoltage (0x3210 / 0x103)
9.3.19
DC link undervoltage (0x3220 / 0x104)
9.3.20
DC link charging error (0x3230 / 0x152)
9.3.21
DC Link unbalanced (0x3280 / 0x153)
9.3.22
UAUX high voltage (0x3291 / 0x132)
9.3.23
UAUX overvoltage (0x3292 / 0x133)
9.3.24
UAUX low voltage (0x3293 / 0x134)
9.3.25
UAUX undervoltage (0x3294 / 0x135)
9.3.26
DC link high voltage (0x3295 / 0x136)
9.3.27
DC link low voltage (0x3296 / 0x137)
9.3.28
UAUX charging error (0x3297 / 0x154)
9.3.29
DC link shutdown error (0x3298 / 0x165)
9.3.30
UAUX shutdown error (0x3299 / 0x155)
9.3.31
UAUX undervoltage hardware (0x329A / 0x156)
9.3.32
Device overtemperature (0x4210 / 0x157)
9.3.33
Device under temperature (0x4220 / 0x138)
9.3.34
Overtemperature: Control card (0x4291 / 0x106)
9.3.35
Overtemperature: Power card (0x4292 / 0x107)
9.3.36
Inrush overtemperature DC link (0x4293 / 013C)
9.3.37
Inrush overtemperature AUX line (0x4294 / 0x13D)
