5.9.5.4 Connecting the 3rd Ethernet Device Cable to Port X3

Illustration 41: Connecting the 3
Procedure
1.
Align the connector on the cable with the Ethernet connector marked X3 on the ISD 510/DSD 510 servo drive.
2.
Press the connector towards the electronic housing of the servo drive and tighten the threaded ring by turning it clockwise.
The maximum tightening torque is 0.2 Nm.

5.9.6 Disconnecting Cables from Ports X3, X4, and X5

1.
Loosen the threaded ring of the connector by turning it counterclockwise.
2.
Disconnect the cable from the servo drive.
3.
Protective blind caps are provided for the X3, X4, and X5 connectors. Mount the blind caps after removing the respective
connector.

5.10 Connecting the Power Supply Module PSM 510

5.10.1 AC Line Choke

It is mandatory to use a 3-phase AC line choke (see
510 Modules to the AC
Choke).
Table 23: Line Choke Characteristics for 1 PSM 510
Model
PSM 510 (10 kW)
PSM 510 (20 kW)
PSM 510 (30 kW)
72 | Danfoss A/S © 2020.08
rd
Ethernet Device Cable
5.10.1.1 Connecting 1 PSM 510 to the AC Choke
Minimum I
[A]
rms
20
40
60
and
5.10.1.2 Connecting 2 PSM
U
[V]
Inductance [mH]
rms
500
Minimum: 0.47
Maximum: 1.47
500
Minimum: 0.47
Maximum: 1.47
500
0.47 ±10%
AQ262449648484en-000101 / 175R1135
