VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
- Firmware for the servo drive
- Firmware for the PSM 510, DAM 510, and ACM 510
- PC software tool: VLT
- PLC libraries
- DanfossMotion library for ISD 510/DSD 510 system for AutomationStudio
- DanfossMotion library for ISD 510/DSD 510 system for TwinCAT
- DanfossMotion library for ISD 510/DSD 510 system for SIMOTION SCOUT
The system modules PSM 510, DAM 510, and ACM 510 are mounted to a backplate located in the control cabinet. DC link and the
control voltage supply are integrated in the backplate. The 'click and lock' backplate concept offers easy mounting and installation.
The ISD 510 servo drives are self-contained distributed drives, whereby the drive electronics is housed together with the motor in
the same casing. The DSD 510 servo drives are decentral servo drives for mounting close to the servo motor.
There are 2 versions of the ISD 510/DSD 510 servo drive:
Version ISD 510/DSD 510
Standard With 2 hybrid connectors (M23) that connect power and communication signals from a hybrid cable.
Advanced As standard plus 3 additional interfaces for external encoder or I/Os, fieldbus devices, and for the local control panel
(LCP) to be connected directly.
The motion control is integrated into the servo drive so that the motion sequences can take place independently. This reduces the
required computing power of the central PLC and offers a highly flexible drive concept. Danfoss offers libraries for various IEC
61131-3 programmable PLCs. Due to the standardized and certified fieldbus interfaces of the devices, any PLC with an EtherCAT
master functionality, or Ethernet POWERLINK
-
The ISD 510/DSD 510 servo drives cannot be used in servo systems from other manufacturers without changing the cabling
infrastructure.
-
Drives from other manufacturers cannot be used in the ISD 510/DSD 510 system when using Danfoss hybrid cables.
-
Size 1 and 2 ISD 510 servo drives cannot be combined on the same line with size 3 and 4 ISD 510 servo drives and DSD 510
servo drives.
-
Only the components described in this manual may be fitted or installed. Third-party devices and equipment may be used
only in consultation with Danfoss.
-
Contact Danfoss for further information.

3.1.1 Application Examples

There are numerous potential areas of application for the servo system as per the following examples.
Beverage machines
• Labeling
• Capping
• Filling
• PET blow-moulding
• Digital bottle printing
Food and beverage packaging machines:
• Flow wrapping
• Bag maker
• Tray sealing
• Shrink wrapping
Industrial and pharmaceutical packaging machines:
26 | Danfoss A/S © 2020.08
Servo Toolbox
®
or PROFINET
®
N O T I C E
.
™
2 and 3.
®
and TiA Portal.
®
managing node functionality according to the standards can be used.
®
System Description
AQ262449648484en-000101 / 175R1135
®
