VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
STATUS PSM STATUS PSM
DEV DEV
SVS ST SVS ST
NET ST NET ST
LINK/ACT LINK/ACT
X1 X1
X2 X2
LCP
Illustration 43: Connecting 2 PSM 510 Modules to the AC Choke

5.10.1.3 Connecting 2 PSM 510 Modules to the AC Choke with System Splitting

Connect the PSM 510 modules to the same AC choke regardless of the load position (for example, before or after the system split-
ting) as shown in Illustration
Ensure the choke used is the correct size based on the combined power of the PSM 510 modules.
When 2 PSM 510 modules are used, the wiring between the AC line choke and each PSM 510 must be the same length within a
tolerance of 0.5 m.
Connect each PSM 510 to the AC choke directly. Parallel wiring is not permitted.
74 | Danfoss A/S © 2020.08
...
STATUS DAM
DEV
SVS ST
NET ST
AUX
LINK/ACT
X1
X2
X3
LCP
LCP
44.
Electrical Installation
AQ262449648484en-000101 / 175R1135
