VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
1
26
Illustration 49: Feed-In Cable
1 Shielded area
2 UDC+ (black, 2.5 mm
3 UDC– (gray, 2.5 mm
4 STO+ (pink, 0.5 mm
5 STO– (gray, 0.5 mm
6
5
4
3
Illustration 50: Connecting the Feed-In Cable
1 Feed-in cable PE screws
2 Bus connector
3 Cable tie for feed-in cable
78 | Danfoss A/S © 2020.08
117
80
10
20
2
3
18 7
4
5
10
6
7
87
8
2 2
/4 mm )
2 2
/4 mm )
2
)
2
)
2
9
6 AUX+ (red, 2.5 mm
7 AUX– (blue, 2.5 mm
8 Ethernet/fieldbus (green, RJ45 connector)
9 PE (yellow/green, 2.5 mm
1
4 Cable tie for STO cable
5 EMC plate
6 EMC plate screw
Electrical Installation
2
)
2
)
2 2
/4 mm , fork lug)
