VLT® Servo Drive System ISD 510/DSD 510
Operating Guide

3.9.2 Motor and Feedback Cable

Pre-configured motor and feedback cables are used to connect the DSD 510 servo drive to a PM motor. Both ends of the cable are
fitted with M23 connectors.
These cables are provided by Danfoss and are available in 2.5 m and 5 m lengths (see the VLT® Servo Drive System ISD 510,
DSD 510, MSD 510 (VLT® Flexmotion
The maximum length between the DSD 510 and the motor is 5 m.
There are different types of cables available according to the feedback and motor variant used. Refer to the following tables for
details of the abbreviations used in the descriptions.
Table 16: Motor and Feedback Cable Types
Ordering number
175G8945
175G8946
175G8947
175G8948
175G8949
175G8950
Table 17: Connector Types (CT)
Type Variant
CT0 –
CT0 1
CT0 2
CT0 3
CT0 4
Table 18: Motor/Cable Configuration
M01
M02
Table 19: Cable Colors
OR
GN

3.9.2.1 Minimum Bending Radius for Motor Cable

The maximum number of bending cycles is 5 million at 7.5 x cable diameter (14.8 mm).
• Permanently flexible: 10 x cable diameter
• Permanently installed: 5 x cable diameter

3.9.2.2 Minimum Bending Radius for Feedback Cable

The maximum number of bending cycles is 5 million at 7.5 x cable diameter (11.7 mm).
• Permanently flexible: 7.5 x cable diameter
• Permanently installed: 5 x cable diameter
42 | Danfoss A/S © 2020.08
) Design Guide for further information).
™
Description
Motor Cable DSD M01 CT01 2.5 m OR
Motor Cable DSD M01 CT01 5.0 m OR
Feedback Cable DSD M01 CT03 RES 2.5 m GN
Feedback Cable DSD M01 CT03 RES 5.0 m GN
Feedback Cable DSD M01 CT04 ENC 2.5 m GN
Feedback Cable DSD M01 CT04 ENC 5.0 m GN
Description
M23
Motor standard with HIPERFACE DSL
Reserved
M23 Resolver
M23 Encoder
AKM Pinout
–
Orange
Green
System Description
