VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
DO NOT USE EXCESSIVE FORCE DURING THE FITTING PROCEDURE:
-
Do not exceed the specified vibration limits.
-
Do not exceed the specified permitted forces.
Procedure
1.
Align the clamping set to the axis of the ISD 510 servo drive.
2. Insert the shaft in the clamping set.
3.
Screw the clamping set together.

4.7.5.4 Tightening Torques for Fixing Screws

Always tighten the screws uniformly and crosswise.
Servo drive size
Size 1, 1.5 Nm
Size 2, 2.1 Nm
Size 2, 2.9 Nm
Size 2, 3.8 Nm
Size 3, 5.2 Nm
Size 3, 6.0 Nm
Size 4, 11.2 Nm
Size 4, 13.0 Nm
-
The fixing screws are not supplied and must be selected according to the machine fixings.

4.7.6 Fitting Instruction for DSD 510 Servo Drive

4.7.6.1 Clamping the DSD 510 Servo Drive

Observe the following fitting instructions to ensure the reliable and effective fitting of the DSD 510 servo drive.
Procedure
1. Check the mounting surface and ensure that it has sufficient heat dispersion capacity. An unpainted surface is mandatory.
2.
Drill the holes for mounting the DSD 510 (see
3. Mount the DSD 510 to the mounting plate using M5 screws.
- The tightening torque is 3 Nm
- Always use all 4 mounting holes.
56 | Danfoss A/S © 2020.08
N O T I C E
Maximum thread length
Thread type/
hole size
Ø 5.8 mm –
M6 pitch 1 mm 23 mm
Ø 7 mm –
Ø 7 mm –
Ø 9 mm –
Ø 9 mm –
Ø 11 mm –
In preparation –
N O T I C E
11.3.3 Dimensions of DSD 510 Servo Drive
Mechanical Installation
Tightening torque
5 Nm
6 Nm
6 Nm
6 Nm
14 Nm
14 Nm
28 Nm
In preparation
).
AQ262449648484en-000101 / 175R1135
