VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
9.3.6 High cont. power overload (0x2313 / 0x161)
This error is valid for PSM 510.
Table 46: High cont. power overload (0x2313 / 0x161)
Code PROFINET code
®
0x2313 0x161
9.3.7 Continuous power overload (0x2314 / 0x162)
This error is valid for PSM 510.
Table 47: Continuous power overload (0x2314 / 0x162)
Code PROFINET code
®
0x2314 0x162
9.3.8 Overcurrent short circuit (0x2320 / 0x163)
This error is valid for PSM 510 and DAM 510.
Table 48: Overcurrent short circuit (0x2320 / 0x163)
Code PROFINET code
®
0x2320 0x163
9.3.9 Ground fault (0x2330 / 0x151)
This error is valid for PSM 510, DAM 510, and ISD 510/DSD 510.
Table 49: Ground fault (0x2330 / 0x151)
Code PROFINET code
®
0x2330 0x151
9.3.10 AUX overcurrent (0x2391 / 0x125)
This error is valid for DAM 510.
Table 50: AUX overcurr (0x2391 / 0x125)
Code PROFINET
®
code
0x2391 0x125
9.3.11 AUX user limit current (0x2393 / 0x127)
This error is valid for DAM 510.
162 | Danfoss A/S © 2020.08
Name Severity (warning/error/trip
lock)
High cont. power Warning, error
overload
Name Severity (warning/error/trip
lock)
Continuous power Warning, error
overload
Name Severity (warning/error/trip
lock)
Overcurrent short Trip lock
circuit
Name Severity (warning/error/trip
lock)
Ground fault Warning, error
Name Severity (warning/error/
trip lock)
AUX overcur- Error
rent
Description
High continuous power
overload error.
Description
Continuous power over-
load error.
Description
Overcurrent short circuit er-
ror.
Description
Discharge from output phases
to ground.
Description
Current on the AUX line has reached
the overcurrent limit.
AQ262449648484en-000101 / 175R1135
Diagnostics
LCP name
high pwr ovld
LCP name
cont pwr ovld
LCP name
over curr short
LCP name
ground fault
LCP name
AUX overcurr
