Danfoss VLT ISD 510 Operating Manual page 171

VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
9.3.53 Homing error on entering homing mode (0x8693 / 0x10F)
This error is valid for ISD 510/DSD 510.
Table 93: Homing error on entering homing mode (0x8693 / 0x10F)
Code PROFINET
®
code
0x8693 0x10F
9.3.54 Homing error on start homing method (0x8694 / 0x110)
This error is valid for ISD 510/DSD 510.
Table 94: Homing error on start homing method (0x8694 / 0x110)
Code PROFINET
®
code
0x8694 0x110
9.3.55 Homing error distance (0x8695 / 0x111)
This error is valid for ISD 510/DSD 510.
Table 95: Homing error distance (0x8695 / 0x111)
Code PROFINET code
®
0x8695 0x111
9.3.56 Mechanical brake failure (0xFF01 / 0x112)
This error is valid for ISD 510/DSD 510.
Table 96: Mechanical brake failure (0xFF01 / 0x112)
Code PROFINET code
®
0xFF01 0x112
9.3.57 Short circuit in mechanical brake control (0xFF02 / 0x113)
This error is valid for ISD 510/DSD 510.
Table 97: Short circuit in mechanical brake control (0xFF02 / 0x113)
Code PROFINET code
®
0xFF02 0x113
9.3.58 External interface power failure (0xFF0A / 0x114)
This error is valid for ISD 510/DSD 510.
Danfoss A/S © 2020.08
Name Severity (warning/
error/trip lock)
Homing error on enter- Warning
ing homing mode
Name Severity (warning/
error/trip lock)
Homing error on start Warning
homing method
Name Severity (warning/error/trip
lock)
Homing error dis- Warning
tance
Name Severity (warning/error/trip
lock)
Mechanical brake Trip lock
failure
Name
Short circuit in mechani-
cal brake control
Description
Could not enter homing mode
(for example velocity not 0).
Description
Could not start homing method
(for example drive not in stand-
still).
Description
Homing distance
reached.
Severity (warning/error/
trip lock)
Trip lock
LCP name
Homing mode
fail
LCP name
Homing meth-
od fail
LCP name
Homing distance
Description LCP name
No brake or wire failure. brake mech fail
Description LCP name
Short circuit in brake brake mech
control. short
AQ262449648484en-000101 / 175R1135 | 171
Diagnostics
