VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
1 Danfoss logo
2 System module name
3 Part number
4 Serial number
5 Output
11.1.2.2 Example Nameplate on the Side of the System Modules
The following data is shown on the nameplate on the side of the system modules:
Illustration 121: Example Nameplate on the Side of the System Modules for PSM 510
1 Type code
2 Supply voltage
3 Output voltage
4 Maximum power
5 Ambient temperature range
11.2 Characteristic Data
11.2.1 Characteristic Data for ISD 510 Servo Drive without Brake
Table 121: Characteristic Data for Servo Drive without Brake
Specifica- Unit Size 1,
tions 1.5 Nm
Rated speed RPM 4600
n
N
Rated tor- Nm 1.5
que M
N
Rated cur- A DC 1.4
rent I
N
186 | Danfoss A/S © 2020.08
6
7
8
9
6
7
8
9
Size 2, Size 2, Size 2,
2.1 Nm 2.9 Nm 3.8 Nm
4000 2900 2400
2.1 2.9 3.8
1.7 1.8
Data matrix
Notes
MAC addresses
Warning symbols
Protection rating: IP20 according to IEC/EN 60529
(except connectors which are IP00)
U supply
AUX
Short-circuit current rating
Rated power
Size 3, Size 3, Size 4,
5.2 Nm 6.0 Nm 11.2 Nm
3000 3000 2000
5.2 6.0 11.2
3.6 3.4 4.7
AQ262449648484en-000101 / 175R1135
Specifications
Size 4,
13.0 Nm
(1)
–
–
–
