3.2.4.2 Brake (Optional)

The optional mechanical holding brake is designed as a single-disc brake. The emergency stop function can be initiated at most
once every 3 minutes and up to 2000 times in total, depending on the load.
The effective holding torque is:
• Size 1: 2.5 Nm
• Size 2: 5.3 Nm
• Size 3: 14.5 Nm
• Size 4: 25 Nm
The brake operates as a holding brake according to the fail-safe principle closed when no current. It is powered from the 24 V DC
auxiliary supply. This enables low-backlash load holding when no current is present.
Electrical data: Power consumption:
• Size 1: 1.5 W
• Size 2: 1.8 W
• Size 3: 3.5 W
• Size 4: 5 W
-
Do not misuse the holding brake as a working brake because this causes increased wear, resulting in premature failure.
-
Using ISD 510 servo drives with brakes can reduce the number of drives allowed, depending on the total length of each
hybrid line.

3.2.4.3 Cooling

The ISD 510 servo drives are self-cooling. Cooling (heat dispersal) is primarily via the flange, with a small amount dispersed by the
housing.

3.2.4.4 Thermal Protection

Thermal sensors monitor the maximum allowable temperature of the motor winding and switch the motor off if the limit of 150 °C is
exceeded. Thermal sensors are also present in the drive to protect the electronics against overtemperature. An error message is sent
via Real-Time Ethernet to the higher-level PLC and is also shown on the LCP.

3.2.4.5 Built-in Feedback Devices

The built-in feedback device measures the rotor position. There are 3 feedback variants available:
• Resolver
• BiSS-B 17 bit single-turn encoder
• BiSS-B 17 bit multi-turn encoder
Data/type
Signal
Accuracy
Resolution
Maximum number of turns

3.2.5 Drive Components

3.2.5.1 Connectors on the ISD 510 Servo Drives

This section details all possible connections for the standard and advanced servo drive.
There are 5 connectors on the ISD 510 servo drives.
Danfoss A/S © 2020.08
N O T I C E
Resolver Single-turn encoder
Sin/cos BiSS-B
±10 arcmin ±1.6 arcmin
14 bit 17 bit
– –
System Description
Multi-turn encoder
BiSS-B
±1.6 arcmin
17 bit
4096 (12 bit)
