VLT® Servo Drive System ISD 510/DSD 510
Operating Guide

4.5.2 ISD 510/DSD 510 Servo Drive

• The allowable operating ambient temperature range and vibration levels must not be exceeded. (See
Servo Drive.)
• The allowable relative humidity range is 3–93%, non-condensing.
• Unrestricted ventilation must be available.
• The mounting structure must be suitable for the application, for example, adequately rigid and able to cope with temperatures
over 90 °C.

4.5.3 System Modules

The environmental conditions for the PSM 510, DAM 510, and ACM 510 are:
• The allowable operating ambient temperature range and vibration levels must not be exceeded (see
• The allowable relative humidity range is 5–93%, non-condensing.
• The minimum space required above and below the system modules is detailed in

4.6 Preparation for Installation

4.6.1 ISD 510/DSD 510 Servo Drive
Make the following preparations to ensure that the servo system can be installed reliably and effectively.
Always fit couplings and other transfer components in accordance with local regulations.
Procedure
1. Provide a suitable mounting arrangement for the application. This depends on the type, weight, and power size of the ISD
510/DSD 510 servo drives.
2.
For the ISD 510 servo drives, seat the motor flange flush against the mounting surface before fixing the servo drive. Mis-
alignment shortens the life of the bearings and the coupling components and reduces heat transfer from the servo drive.
3.
For the DSD 510 servo drives, seat the bottom side of the DSD 510 to the mounting surface before fixing the servo drive.
Misalignment reduces heat transfer from the servo drive.
4. Provide contact protection according to local regulations if hot surfaces can be expected during operation.
5. Ground the servo drive.
4.6.2 System Modules
Make the following preparations to ensure that the servo system can be installed reliably and effectively.
Always fit the system modules in accordance with local regulations.
Procedure
1.
Provide a suitable mounting arrangement for the application. This depends on the type and weight of the modules.
2. To avoid misalignment, ensure that the backplates are perfectly level.
3.
To ensure sufficient cooling, pay attention to the specified minimum space requirements.
4. Ground the modules.
Danfoss A/S © 2020.08
Mechanical Installation
11.10.1 ISD 510/DSD 510
11.10.2 System
4.7.3 Space Requirements for System
AQ262449648484en-000101 / 175R1135 | 49
Modules).
Modules.
