Table 133: Pin Assignment of X6 Motor Connector
Pin Description Notes
1 U Motor phase U
PE PE Protective earth
3 W Motor phase W
4 V Motor phase V
A Brake+ Used to connect the motor's
mechanical brake (if present).
B Brake–
C Data– HIPERFACE DSL negative line
(1)
D Data+ HIPERFACE DSL positive line
(1)
The data+/– signals are only present on the HIPERFACE DSL variant, otherwise both are not connected.
1
11.9 Connectors on the System Modules
11.9.1 Backlink Connector
The backlink connector is located at the top of the backside of all the ISD 510 system modules.
