VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
Illustration 145: U Connector
AUX
Table 139: Pin Assignment of U
De- Notes
Pins
scrip-
(left to
tion
right)
1 24 V Used for 24–48 V DC in-
AUX put to the Power Supply
Module (PSM 510).
2 GND
-
Only PELV potential can be connected to the U
11.9.5.1 24/48 V Cable Cross Sections for PSM 510
Minimum cable cross section for CE (minimum 70 °C, Cu)
Minimum cable cross section for UL (minimum 60 °C, Cu)
11.9.6 LCP Connector (M8, 6-pole)
The LCP connector is located on the front of all the system modules. It used to connect the LCP directly via a cable.
4
3
6
5
2
1
Illustration 146: LCP Connector (M8, 6 pole)
Table 140: Pin Assignment of LCP Connector
Pins Description
1 Not connected
2 /LCP RST
3 LCP RS485
4 /LCP RS485
206 | Danfoss A/S © 2020.08
Connector
AUX
Rating/parameter
Nominal input voltage: 24 V/48 V DC ±10%
Nominal current: Depends on the number of servo drives in the application.
Maximum current: 50 A
Maximum cross-section: 16 mm
Maximum cable length: 3 m
Conductor cross-section range 0.75–16 mm
N O T I C E
input.
AUX
Notes
–
Reset
Positive RS485 signal
Negative RS485 signal
2
2
, solid or flexible (AWG 18–AWG 4)
Rating/parameter
–
Active at ≦0.5 V
Speed:
38.4 kBd
The levels fulfill the RS485 specification.
AQ262449648484en-000101 / 175R1135
Specifications
2
16 mm
4 AWG
