• Minimum hardware requirements: 512 MB RAM, Intel Pentium 4 with 2.6 GHz or equivalent, 20 MB hard disk space.
• Recommended hardware requirements: Minimum 1 GB RAM, Intel Core i5/i7 or compatible.
6.17.3 Installing the VLT® Servo Toolbox Software
Administrator rights are required to install the software with the Windows operating system. If necessary, contact your system ad-
ministrator.
Procedure
1.
Check that your system meets the system requirements specified in
2. Download the VLT Servo Toolbox installation file from the Danfoss website.
®
3.
Right-click on the .exe file and select Run as administrator.
4. Follow the on-screen instructions to complete the installation process.
6.17.4 VLT® Servo Toolbox Communication
6.17.4.1 Overview
This chapter describes the Ethernet-specific network interface settings needed by the VLT
nication methods: direct communication and indirect communication. Their particular network settings are described in the respec-
tive subchapters.
Read and perform the steps with care. Incorrect network configurations can lead to loss of connectivity of a network interface.
6.17.4.2 Firewall
Depending on the firewall settings and the fieldbus used, the messages sent and received by the VLT
blocked by the firewall on the VLT
municate with the devices on the fieldbus. Therefore, ensure that the VLT
firewall on the VLT Servo Toolbox host system. Inappropriate changes to firewall settings may lead to security issues.
®
-
When using a dedicated network interface, the VLT
this network interface.
6.17.4.3 Indirect Communication
6.17.4.3.1 Overview
Communication between ISD 510/DSD 510 devices and the VLT
Ethernet-based fieldbus communication (marked A in the graphic) takes place between the PLC and the ISD 510/DSD 510 devices.
However, there is non-fieldbus communication between the PLC and the VLT
In the scenario shown, the PLC has the master function and uses cyclic communication with the devices. Therefore, not all function-
alities of the VLT Servo Toolbox, for example the drive control, can be used.
®
The restrictions when using indirect communication are detailed in the VLT® Servo Drive System ISD 510, DSD 510, MSD 510 (VLT®
Flexmotion ) Programming Guide.
™
