VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
Table 78: Overtemperature: Motor (0x4310 / 0x108)
Code PROFINET code
®
0x4310 0x108
9.3.39 Charge switch failure voltage (0x5121 /0x158)
This error is valid for PSM 510.
Table 79: Charge switch failure voltage (0x5121 / 0x158)
Code PROFINET
®
code
0x5121 0x158
9.3.40 EE Checksum Error (parameter missing) (0x5530 / 0x10A)
This error is valid for ISD 510/DSD 510.
Table 80: EE Checksum Error (parameter missing) (0x5530 / 0x10A)
Code PROFINET
®
code
0x5530 0x10A
9.3.41 Parameter error (0x6320 / 0x10B)
This error is valid for PSM 510, DAM 510, ACM 510, and ISD 510/DSD 510.
Table 81: Param err (0x6320 / 0x10B)
Code PROFINET code
®
0x6320 0x10B
9.3.42 Conf par ver (0x6382 / 0x15D)
This error is valid for PSM 510, DAM 510, ACM 510, and ISD 510/DSD 510.
Table 82: Configuration parameters version error (0x6382 / 0x15D)
Code PROFINET Name
®
code
0x6382 0x15D Configuration param-
eters version error
9.3.43 Configuration parameters limits error (0x6383 / 0x164)
This error is valid for PSM 510, DAM 510, and ACM 510.
168 | Danfoss A/S © 2020.08
Name Severity (warning/error/trip
lock)
Overtemperature: Error
Motor
Name Severity (warning/
error/trip lock)
Charge switch Trip lock
failure voltage
Name Severity (warning/
error/trip lock)
EE Checksum Error (pa- Trip lock
rameter missing)
Name Severity (warning/error/trip
lock)
Parameter error Trip lock
Severity (warning/
error/trip lock)
Trip lock
Description
Overtemperature on mo-
tor.
Description
Indicates a malfunction of the in-
ternal charge circuit.
Description
EEPROM checksum error or miss-
ing device parameter.
Description
A parameter has an invalid value.
Description
Configuration parameter set version mis-
match: parameter set is not valid for this
device.
AQ262449648484en-000101 / 175R1135
Diagnostics
LCP name
overtemp motor
LCP name
Chg switch
fail
LCP name
eeprom err
LCP name
param err
LCP name
conf par
ver
