VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
Illustration 2: Connectors on the ISD 510 Servo Drive
Table 7: Connectors on the ISD 510 Servo Drive
Connector
X1
X2
X3 (advanced version only)
X4 (advanced version only)
X5 (advanced version only)
-
Detailed information on each of the connectors can be found in
3.3 VLT® Decentral Servo Drive DSD 510

3.3.1 Overview of the DSD 510 Servo Drive

DSD is the abbreviation of decentral servo drive, which is a servo drive for mounting close to the servo motor. In this way, the servo
motor has no impact to the DSD 510 servo drive from a thermal point of view.
The DSD 510 servo drive extends the selection of a decentral servo drive concept. It delivers rated power up to 4.5 kW and can be
used with a wide range of permanent magnet servo motors and motor feedback encoders.
LEDs on the top of the DSD 510 servo drive show the current status. Data transfer takes place via Real-Time Ethernet.

3.3.2 DSD 510 Servo Drive Types

-
The Drive Configurator shows the valid configuration of servo drive variants. Only valid combinations are shown. Therefore,
not all variants detailed in the type code are visible.
Table 8: Type Code DSD 510
1–3 4–6 7 8–12
DSD 510 C08A0
30 | Danfoss A/S © 2020.08
Description
M23 connector for feed-in or loop hybrid cable input
M23 connector for loop hybrid cable output or fieldbus extension cable
M8 connector for Ethernet cable (minimum CAT5, shielded)
M12 connector for I/O and/or encoder cable (shielded)
M8 connector for LCP cable (shielded)
N O T I C E
N O T I C E
13–14 15–17 18–20
D6 E67
11.8 Connectors on the ISD 510/DSD 510 Servo
21–22 23–25 26 27–28
SXX T F2
System Description
Drive.
29–30 31–38 39–40
XXXXXXXX
AQ262449648484en-000101 / 175R1135
