VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
LED
(State of the auxiliary voltage)
LINK/ACT X1
(Link/activity of In)
LINK/ACT X2
(Link/activity status of Hybrid Out)
LINK/ACT X3
(Link/activity status of Out)
7.2.4 Operating LEDs on the ACM 510
STATUS ACM
DEV
CAP ST
NET ST
LINK/ACT
X1
X2
Illustration 107: Operating LEDs on ACM 510
Table 33: Operating LEDs on ACM 510
LED
DEV
CAP ST
Danfoss A/S © 2020.08
Color Flash status
Off
Red On
Green On
Flashing
Off
Green On
Flashing
Off
Green On
Flashing
Off
Color Flash status
Green On
Flashing
Red On
Flashing
Green On
Flashing
Description
Auxiliary voltage is not applied to the output connector.
Auxiliary voltage undervoltage detected in the hardware.
Ethernet link established.
Ethernet link established and active.
No link.
Ethernet link established.
Ethernet link established and active.
No link.
Ethernet link established.
Ethernet link established and active.
No link.
Description
Device is in state Operation enabled.
Device is in state Standby or Power-up.
Device is in state Fault or Fault reaction active.
DC-link is not applied at the input.
Capacitors fully charged.
Capacitors charging/discharging.
