discovery. Disabling these protocols reduces the number of non-relevant packets sent over the network interface and thus reduces
the overall network load.
6.17.5 VLT® Servo Toolbox Commissioning
6.17.5.1 Step 1: Opening the Main Window
The Main Window is the basis for all VLT
1
2
3
4
5
6
7
8
9
Illustration 102: Main Window
Table 29: Main Window Description
Leg- Name
end
num-
ber
1 Menu bar
2 Tool bar
3 Online status
and state in-
formation
138 | Danfoss A/S © 2020.08
Servo Toolbox functionalities. It consists of the following components:
®
Description
Contains the general functionalities for saving and loading projects, managing connections, showing
and changing settings, managing open subtools, and showing help contents.
Contains shortcuts for saving and loading projects, connecting to and disconnecting from networks,
automatic searching for online devices, and manually adding devices.
Online devices are indicated by a glowing light bulb next to the device ID.
• An online device is a logical device for which a physical device exists that the VLT
connected to.
• The color indicates the state of the device and is device-specific.
Commissioning
Servo Toolbox is
®
