LED
LINK/ACT X1
(Link/activity status of In)
LINK/ACT X2
(Link/activity status of Out)
7.2.3 Operating LEDs on the DAM 510
STATUS DAM
DEV
SVS ST
NET ST
AUX
LINK/ACT
X1
X2
X3
Illustration 106: Operating LEDs on DAM 510
Table 32: Operating LEDs on DAM 510
LED
DEV
SVS ST
NET ST
AUX
144 | Danfoss A/S © 2020.08
Color Flash status
Green On
Flashing
Off
Green On
Flashing
Off
Color Flash status
Green On
Flashing
Red On
Flashing
Green On
Off
Green On
Orange On
Red Flashing
On
Green On
Description
Ethernet link established.
Ethernet link established and active.
No link.
Ethernet link established.
Ethernet link established and active.
No link.
Description
Device is in state Operation enabled.
Device is in state Standby or Power-up.
Device is in state Fault or Fault reaction active.
DC-link is not applied at the input.
24 V safety supply is applied.
24 V safety supply is not applied.
Connected.
Online.
Initialization.
Initialization failed or other error.
Auxiliary voltage is applied to the output connector.
