9 Diagnostics
9.1 Faults
If faults occur during the operation of the ISD 510/DSD 510 system, check:
• The LEDs on the servo drives for general problems relating to communication or device status.
• The LEDs on the PSM 510 and DAM 510 for general problems with communication, auxiliary supply, or STO voltage.
• The error codes.
The error codes can be read using the VLT
device it is connected to.
-
If the fault cannot be eliminated by 1 of the measures listed in the troubleshooting tables, notify Danfoss Service.
Have the following information available to enable Danfoss to provide help quickly and effectively:
• Type number
• Error code
• Firmware version
• System setup (for example, number of servo drives, system modules, and lines).
• System status when the fault occurred.
• Ambient conditions.
9.2 Troubleshooting
9.2.1 Troubleshooting for the ISD 510/DSD 510 Servo Drives
9.2.1.1 Drive not Running/Starting Slowly
Possible Cause
• Bearing wear.
• Incorrect parameter settings.
• Incorrect control loop parameters.
• Incorrect torque settings.
Troubleshooting
• Check the bearings and the shaft.
• Check the parameter settings.
9.2.1.2 Drive Hums and Draws High Current
Possible Cause
• Drive defective.
Troubleshooting
• Contact Danfoss.
9.2.1.3 Drive Stops Suddenly and Restart is not Possible
Possible Cause
• No drive communication.
• Servo drive in error mode.
Troubleshooting
• Check the fieldbus connection and the LEDs on the servo drive.
