Table 88: External brake chopper overload (0x7182 / 0x143)
Code PROFI- Name
NET
®
code
0x7182 0x143 External
brake chop-
per over-
load
9.3.49 Brake mains voltage too high (0x7183 / 0x159)
This error is valid for PSM 510.
Table 89: Brake mains voltage too high (0x7183 / 0x159)
Code PROFINET Name
®
code
0x7183 0x159 Brake mains
voltage too
high
9.3.50 Internal position sensor error (0x7320 / 0x10C)
This error is valid for ISD 510/DSD 510.
Table 90: Internal position sensor error (0x7320 / 0x10C)
Code PROFINET
®
code
0x7320 0x10C
9.3.51 External position sensor error (0x7380 / 0x10D)
This error is valid for DAM 510 and ISD 510/DSD 510.
Table 91: External position sensor error (0x7380 / 0x10D)
Code PROFINET
®
code
0x7380 0x10D
9.3.52 Following error (0x8611 / 0x10E)
This error is valid for ISD 510/DSD 510.
Table 92: Following error (0x8611 / 0x10E)
Code PROFINET code
®
0x8611 0x10E
170 | Danfoss A/S © 2020.08
Severity (warn- Description
ing/error/trip
lock)
Warning, error
The power load of the brake chopper is monitored during
operation.
Depending on the configuration of external brake chopper
power monitoring this warning or fault appears when the
configured nominal external brake chopper power is
reached.
Severity (warn-
ing/error/trip
lock)
Warning
Name Severity (warning/error/
trip lock)
Internal position sensor Trip lock
error
Name Severity (warning/
error/trip lock)
External position sensor Error
error
Name Severity (warning/error/trip
lock)
Following error Warning, error
Description
The mains voltage is too high.Due to this, the brake
chopper could be activated continuously depending
on the value entered in parameter brake chopper start
level.
Description
Absolute position sensor er-
ror.
Description
External encoder data could
not be read.
Description
A following error has occurred.
Diagnostics
LCP name
ext brake
ch ovl
LCP name
brake ch
high volt
LCP name
int sensor err
LCP name
ext sensor err
LCP name
following err
