6.13.2 Connecting to the PLC

Information on how to connect to the PLC can be found in detail in the SIMOTION SCOUT
Open SIMOTION SCOUT® and go to [Help → Help Topics → Getting Started with SIMOTION SCOUT → Download the project to the
target system → Connect to selected target devices → Go online].
6.13.3 Creating a SIMOTION SCOUT® Project
Information on how to install SIMOTION SCOUT®
-
SIMATIC STEP 7 V5.5 or higher with HF11 must be installed to create a project.
Information on how to create a project in SIMOTION SCOUT
SIMOTION SCOUT and go to [Help → Help Topics → Getting started with SIMOTION SCOUT → Create SIMOTION device and config-
®
ure PG/PC communication connection].
6.13.4 Including the Servo Motion Libraries into a SIMOTION SCOUT® Project
The folder LIBRARIES in the Project tab contains these libraries:
• DDS_Drive
- Contains program organization units (POUs) defined by PLCopen
(name starting with DD_). The Danfoss POUs provide additional functionality for the servo drive.
- It is possible to combine POUs defined by PLCopen
- The names of the POUs that target the servo drive all end with _DDS.
• DDS_PSM
- Contains POUs defined by Danfoss (name starting with DD_) and provide the functionality for the Power Supply Module
(PSM 510).
- The names of the POUs that target the PSM 510 all end with _PSM.
• DDS_DAM
Danfoss A/S © 2020.08
File required
GSDML file (General station description):
GSDML-V2.xx-Danfoss-SDM-yyyymmdd.xml
GSDML file (General station description):
GSDML-V2.xx-Danfoss-ISD-yyyymmdd.xml
GSDML file (General station description):
GSDML-V2.xx-Danfoss-DSD-yyyymmdd.xml
GSDML file (General station description):
GSDML-V2.xx-Danfoss-PSM-yyyymmdd.xml
GSDML file (General station description):
• GSDML-V2.xx-Danfoss-DAM-2Port-IRT-yyyymmdd.xml
• GSDML-V2.xx-Danfoss-DAM-3Port-RT-yyyymmdd.xml
GSDML file (General station description):
GSDML-V2.xx-Danfoss-ACM-yyyymmdd.xml
can be found in detail in the SIMOTION SCOUT
®
N O T I C E
can be found in detail in the SIMOTION SCOUT
®
with POUs defined by Danfoss.
®
Help.
®
Configuration Manual.
®
(name starting with MC_) and POUs defined by Danfoss
®
AQ262449648484en-000101 / 175R1135 | 107
Commissioning
online help. Open
®
