VLT® Servo Drive System ISD 510/DSD 510
Operating Guide
An example type code for the ACM 510 is: MSD510ACM510F1E00C8D6E20PLSXXXXXXXXXXXXX.
1
2
STATUS ACM
DEV
CAP ST
NET ST
LINK/ACT
X1
X2
3
LCP
4
Illustration 6: ACM 510
1 Connectors: I/O, relay, and Ethernet
2 Operating LEDs

3.7 Expansion Module EXM 510

The EXM 510 supports modular machine setup by splitting the system modules into 2 control cabinets. The maximum length of the
cable between the EXM 510 modules is 5 m.
See 5.13 Connecting the Expansion Module EXM 510
Danfoss A/S © 2020.08
3 LCP connector
4 PE screw
for further information.
System Description
AQ262449648484en-000101 / 175R1135 | 35
