Table 83: Configuration parameters limits error (0x6383 / 0x164)
Code PROFINET Name
®
code
0x6383 0x164 Configuration pa-
rameters limits er-
ror
9.3.44 Power EEprom configuration error (0x6384 / 0x166)
This error is valid for PSM 510, DAM 510, ACM 510, and ISD 510/DSD 510.
Table 84: Power EEprom configuration error (0x6384 / 0x166)
Code Name
0x6384 0x166 Power Eeprom config-
uration error
9.3.45 Brake chopper failure (0x7111 / 0x141)
This error is valid for PSM 510.
Table 85: Brake chopper failure (0x7111 / 0x141)
Code PROFINET Name
®
code
0x7111 0x141 Brake chop-
per failure
9.3.46 Brake chopper overcurrent (0x7112 / 0x167)
This error is valid for PSM 510.
Table 86: Brake chopper overcurrent (0x7112 / 0x167)
Code PROFINET
®
code
0x7112 0x167
9.3.47 Brake chopper module overload (0x7181 / 0x142)
This error is valid for PSM 510.
Table 87: Brake resistor maximum power limit (0x7181 / 0x142)
Code PROFINET Name
®
code
0x7181 0x142 Brake chop-
per module
overload
9.3.48 External brake chopper overload (0x7182 / 0x143)
This error is valid for PSM 510.
Danfoss A/S © 2020.08
Severity (warn-
ing/error/trip
lock)
Trip lock
Severity (warning/
error/trip lock)
Trip lock
Severity (warning/
error/trip lock)
Warning, error
Name Severity (warning/error/
trip lock)
Brake chopper Trip lock
overcurrent
Severity (warning/
error/trip lock)
Warning, error
Description
≥1 parameter in the configuration parameter
set is out of limits: the parameter set is not val-
id for this device.
Description
The power device Eeprom is corrupt or
incompatible with this control board.
Description
The brake chopper is monitored during oper-
ation.
A brake failure has been detected by the
brake check function.
Description
The brake chopper current ex-
ceeds the limit.
Description
The power load of the brake chopper is monitored
during operation. This error appears when the maxi-
mum power limit of the brake chopper module is
reached.
AQ262449648484en-000101 / 175R1135 | 169
Diagnostics
LCP name
conf par
lim
LCP name
conf par EE-
PROM
LCP name
brake ch fail
LCP name
brake ch over-
curr
LCP
name
mod ovl
