1.3 Safety guidelines







1.3.1 Delivery and installation





Note:

Select appropriate moving and installing tools to ensure a safe and normal running of the
VFD and avoid physical injury or death. For physical safety, the erector should take some
mechanical protective measurements, such as wearing exposure shoes and working
uniforms.
Name
Physical hurt may occur if related
Note
requirements are not followed
Only qualified electricians are allowed to operate on the VFD.
Do not carry out any wiring and inspection or changing components when
the power supply is applied. Ensure all input power supply is
disconnected before wiring and checking and always wait for at least the
time designated on the VFD or until the DC bus voltage is less than 36V.
Below is the table of the waiting time:
VFD model
1PH 220V
3PH 220V
3PH 380V
Do not refit the VFD unauthorizedly; otherwise fire, electric shock or other
injury may occur.
The base of the radiator may become hot during running. Do not touch to
avoid hurt.
The electrical parts and components inside the VFD are electrostatic.
Take measurements to avoid electrostatic discharge during relevant
operation.
Install the VFD on fire-retardant material and keep the VFD away from
combustible materials.
Connect the braking optional parts according to the wiring diagram.
Do not operate on the VFD if there is any damage or components loss to
the VFD.
Do not touch the VFD with wet items or body, otherwise electric shock
may occur.
Instruction
0.2kW-2.2kW
0.2kW-2.2kW
0.75kW-2.2kW
-2-
Safety precautions
Minimum waiting time
5 minutes
5 minutes
5 minutes
Abbreviation
Note
