Goodrive100-PV Series Solar Pump Inverter
1.3 Safety guidelines
1.3.1 Delivery and installation
Note:
Select appropriate moving and installing tools to ensure a safe and normal running of the
inverter and avoid physical injury or death. For physical safety, the erector should take
some mechanical protective measurements, such as wearing safety shoes and working
uniforms.
Do not carry the inverter by its cover. The cover may fall off.
Ensure to avoid physical shock or vibration during delivery and installation.
Install away from children and other public places.
The leakage current of the inverter may be above 3.5mA during operation. Ground with
proper techniques and ensure the grounding resistor is less than 10Ω. The conductivity of
Only qualified electricians are allowed to operate on the inverter.
Do not carry out any wiring and inspection or changing components
when the power supply is applied. Ensure all input power supply is
disconnected before wiring and checking and always wait for at least the
time designated on the inverter or until the DC bus voltage is less than
36V. Below is the table of the waiting time:
Inverter model
1PH 220V
3PH 220V
3PH 380V
3PH 380V
Do not refit the inverter unauthorized; otherwise fire, electric shock or
other injury may occur.
The base of the radiator may become hot during running. Do not touch to
avoid hurt.
The electrical parts and components inside the inverter are electrostatic.
Take measurements to avoid electrostatic discharge during relevant
operation.
Please install the inverter on fire-retardant material and keep the inverter
away from combustible materials.
Do not operate on the inverter if there is any damage or components
loss to the inverter.
Do not touch the inverter with wet items or body, otherwise electric shock
may occur.
0.4kW-2.2kW
1.5kW-7.5kW
0.75kW-110kW
132kW-200kW
-2-
Safety precautions
Minimum waiting time
5 minutes
5 minutes
5 minutes
15 minutes
