inverters
Goodrive300
Function
code
output to the upper limit
P06.21 AO1 output filter time
P06.22 Lower limit of AO2 output
Corresponding AO2
P06.23
output to the lower limit
P06.24 Upper limit of AO2 output
Corresponding AO2
P06.25
output to the upper limit
P06.26 AO2 output filter time
P06.27 Lower limit of HDO output 0.0%~P06.25
Corresponding HDO
P06.28
output to the lower limit
P06.29 Upper limit of HDO output P06.23~100.0%
Corresponding HDO
P06.30
output to the upper limit
P06.31 HDO output filter time

7.11 Digital input

Goodrive300 series inverters have 8 programmable digital input terminals and 1 open circuit
electrode output terminal in the standard configuration. All functions of the digital input terminals
are programmable by the function codes. Open collector pole input can be selected into high
speed pulse input terminal or common switch input terminal by function code. When selected into
HDI, the user can select HDI high speed pulse input as frequency given, counting input or length
pulse input by setting.
Name
0.000s~10.000s
0.0%~P06.20
0.00V~10.00V
P06.18~100.0%
0.00V~10.00V
0.000s~10.000s
0.00~50.00kHz
0.00~50.00kHz
0.000s~10.000s
Detailed instruction of parameters
183
Basic operation instruction
Default
value
0.000s
0.0%
0.00V
100.0%
10.00V
0.000s
0.00%
0.0kHz
100.0%
50.00kHz
0.000s
