P06.17 Lower output limit of AO1
Corresponding AO1
P06.18
P06.19 Upper output limit of AO1
The corresponding AO1
P06.20
output of upper limit
P06.21 AO1 output filter time
P06.22 Lower output limit of AO2
Corresponding AO2
P06.23
P06.24 Upper output limit of AO2
The corresponding AO2
P06.25
output of upper limit
P06.26 AO2 output filter time
P06.27 Lower output limit of HDO 0.0%~P06.25
Corresponding HDO
P06.28
P06.29 Upper output limit of HDO P06.23~100.0%
Corresponding HDO
P06.30
output of upper limit
P06.31 HDO output filter time

7.11 Digital input

Goodrive300 series inverters have 8 programmable digital input terminals and 1 open circuit
electrode output terminal in the standard configuration. All functions of the digital input terminals
are programmable by the function codes. Open collector pole input can be selected into high
speed pulse input terminal or common switch input terminal by function code. When selected into
HDI, the user can select HDI high speed pulse input as frequency given, counting input or length
pulse input by setting.
Name
output of lower limit
output of lower limit
output of lower limit
Detailed instruction of parameters
24~30:Reserved
0.0%~P06.15
0.00V~10.00V
P06.13~100.0%
0.00V~10.00V
0.000s~10.000s
0.0%~P06.20
0.00V~10.00V
P06.18~100.0%
0.00V~10.00V
0.000s~10.000s
0.00~50.00kHz
0.00~50.00kHz
0.000s~10.000s
187
Basic operation instruction
Default
value
0.0%
0.00V
100.0%
10.00V
0.000s
0.0%
0.00V
100.0%
10.00V
0.000s
0.00%
0.0kHz
100.0%
50.00kHz
0.000s
