Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
1
39 °C
2
A
4
6
Quick
Status
B
Menu
7
10
C
On
15
Warn.
16
Alarm
17
Hand
D
Off
On
18
19
1 Temperature power card
3 Temperature capacitor bank 2
5 Actual UDC (voltage)
Illustration 23:
Display Area when Connected to the Auxiliary Capacitors Module ACM 510
3.7.2.2 B: Display menu keys
Menu keys are used for menu access for parameter set-up, toggling through status display modes during normal operation, and
viewing fault log data.
Table 5: Display Menu Keys
Key
6
Status
7
Quick Menu
8
Main Menu
9
Alarm Log
40 | Danfoss A/S © 2019.10
3
38 °C
40 °C
24 V
5
565 V
9
Main
Alarm
Menu
Log
8
11
12
OK
13
Auto
Reset
On
14
20
21
Function
Shows operational information.
Allows access to parameters.
Allows access to parameters.
Shows the last 10 alarms.
2 Temperature capacitor bank 1
4 AUX line voltage
System Description
AQ262450196490en-000101 / 175R1170
