Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
5 Electrical Installation
5.1 Warnings for Electrical Installation
During electrical installation, observe the relevant local and national regulations in addition to the information in this manual.
LEAKAGE/GROUNDING CURRENT HAZARD
Leakage/grounding currents are >3.5 mA. Improper grounding of the MSD 510 system modules may result in death or serious
injury.
For reasons of operator safety, use a certified electrical installer to ground the system correctly in accordance with the
-
applicable local and national electrical standards and directives, and the instructions in this manual.
HIGH VOLTAGE
The MSD 510 system contains components that operate at high voltage when connected to the electrical supply network.
There are no indicators on the components that indicate the presence of mains supply. Incorrect installation, commissioning, or
maintenance may lead to death or serious injury.
Installation, commissioning, and maintenance may only be performed by qualified personnel.
-
HIGH VOLTAGE
Potentially lethal voltage is present on the connectors that may lead to death or serious injury.
Before working on the power connectors (disconnecting or connecting the cable), disconnect the PSM 510 from the mains
-
and wait for the discharge time to elapse.
5.2 Electrical Environmental Conditions
Compliance with the following electrical environmental conditions is necessary to enable safe and effective operation of the servo
system:
•
Only for use in TN-S, TN-C, TN-CS, TT (not corner earthed) supply earthing system
•
Prospective short-circuit current: 5 kA
•
Protective class I
•
Grounded 3-phase mains network, 400–480 V AC ±10%
•
3-phase frequency 44–66 Hz
•
3-phase lines and PE line
•
External supply for auxiliary voltage, 24–48 V DC (PELV)
•
AC choke (see
5.9.1 AC Line
•
Observe the national statutory provisions.
•
The leakage current is >3.5 mA.
Danfoss A/S © 2019.10
W A R N I N G
W A R N I N G
W A R N I N G
Choke)
Electrical Installation
AQ262450196490en-000101 / 175R1170| 57
