Table 74: Inrush overtemperature: DC link (0x4293 / 0x13C)
Code
®
PROFINET
code
0x4293 0x13C

9.3.40 Inrush overtemperature AUX line (0x4294 / 0x13D)

This error is valid for DAM 510.
Table 75: Inrush overtemperature AUX line (0x4294 / 0x13D)
Code
®
PROFINET
code
0x4294 0x13D

9.3.41 Overtemperature: Motor (0x4310 / 0x108)

This error is valid for SDM 511/SDM 512.
Table 76: Overtemperature: Motor (0x4310 / 0x108)
Code
®
PROFINET code
0x4310 0x108

9.3.42 UAUX undervoltage (0x5112 / 0x109)

This error is valid for SDM 511/SDM 512.
Table 77: Short circuit (0x5112 / 0x109)
Code
®
PROFINET
code
0x5112 0x109

9.3.43 Charge switch failure voltage (0x5121 /0x158)

This error is valid for PSM 510 and SDM 511/SDM 512.
Danfoss A/S © 2019.10
Name Severity (warning/
error/trip lock)
Inrush overtem- Error
perature: DC link
Name Severity (warning/
error/trip lock)
Inrush overtem- Error
perature AUX line
Name Severity (warning/error/
trip lock)
Overtemperature: Error
Motor
Name Severity (warning/error/
trip lock)
UAUX under- Error, trip lock
voltage
Description
Inrush fault.
Too many transitions into state Operation
enabled in a short time period.
Description
Inrush fault.
Too many power-ups of the AUX voltage
have occurred within a short time period.
Description
Overtemperature on mo-
tor.
Description
Undervoltage on auxiliary
voltage.
AQ262450196490en-000101 / 175R1170| 181
Diagnostics
LCP name
inrush UDC
LCP name
inrush
UAUX
LCP name
overtemp motor
LCP name
undervolt UAUX
